Cisco UCS 5108 Spec Sheet

Cisco UCS 5108 Blade Server Chassis
CONFIGURING the CHASSIS
11
STEP 1 VERIFY BASE CHASSIS SKU
Verify the product ID (PID) of the base 5108 chassis as shown in Table 4. Note that you can order
either an AC-powered or DC-powered version of the chassis.
Included with AC and DC versions:
■ N20-CAK: Chassis Accessory Kit, consisting of:
— N20-CRMK2: One Rail kit that supports square-holed racks (or round hole racks with
an optional adapter - see below)
— N20-BKVM=: KVM local console connector dongle cable that connects to the front of
any UCS blade server, and documentation
— N20-FAN5: Eight redundant and hot-swappable fan modules
Not included with AC or DC versions (but may be ordered separately):
■ N20-CRMK2=: Additional or spare rail kit for the Cisco UCS 5108 chassis
■ N20-CRMK2-RHA=: Round hole adapter kit (for threaded and non-threaded holes) for the rail
kit (N20-CRMK2) included with the chassis.
Caveats
■ You must select either an AC or DC version of the 5108 chassis.
■ There is no mixing allowed of AC and DC power supplies within the same 5108 chassis.
Table 4 PID of the Base 5108 Chassis
Product ID (PID) Description
N20-C6508 AC-powered version of the Cisco UCS 5108 Blade Server Chassis
UCSB-5108-DC DC-powered version of the Cisco UCS 5108 Blade Server Chassis
NOTE: The adapter kit only works with the N20-CRMK2 rail kit

Cisco UCS 5108 Specifications

General

Number of Blade Slots	8
I/O Module Bays	2
Supported Blade Servers	Cisco UCS B-Series Blade Servers
Power Supply Options	Up to four hot-swappable power supplies (AC or DC)
Cooling	Redundant hot-swappable fans
Management	Cisco UCS Manager
Blade Slots	8
Fabric Interconnects	Cisco UCS 6100 or 6200 Series
Power Supplies	Up to 4 hot-pluggable power supplies
Form Factor	6RU rack-mountable
