Cisco UCS 5108 Blade Server Chassis
12
CONFIGURING the CHASSIS
STEP 2 SELECT FABRIC I/O EXTENDERS
The Fabric I/O Extender options are:
■ Cisco UCS 2208XP
■ Cisco UCS 2204XP
■ Cisco UCS 2104XP
Choose Fabric I/O Extenders
The available Fabric I/O Extenders are listed in Table 5. Each Fabric I/O Extender connects to
the Fabric Interconnect 6100 series modules by means of several ports of 10GbE and Fibre
Channel over Ethernet (FCoE).
Approved Configurations
(1) Choose one or two identical Fabric I/O Extenders, or
(2) Choose one or two identical Fabric Extender bundles (includes one Fabric Extender plus
transceivers)
Caveats
■ You must select either one or two identical Fabric I/O Extenders or bundles.
■ Do not use any Fabric Extender transceivers other than those that come in the bundles.
Table 5 Available Fabric I/O Extenders
Product ID (PID) Fabric I/O Extender
Number of
10GbE/FCoE
Ports to Fabric
Interconnect
Number of Internal
10GbE/FCoE Ports
Tota l
Chassis I/O
per Fabric
Extender
UCS-IOM-2208XP 2208XP 8 32 80 Gbs
UCS-IOM2208-16FET Bundle that includes one
2208XP plus 16 Fabric
Extender Transceivers (FETs)
1
Notes . . .
1. For more information on Fabric Extender bundles, see Fabric Extender Bundles on page 42.
8 32 80 Gbs
UCS-IOM-2204XP 2204XP 4 16 40 Gbs
UCS-IOM2204-8FET Bundle that includes one
2204XP plus 8 Fabric
Extender Transceivers (FETs)
1
4 16 40 Gbs
N20-I6584 2104XP 4 8 40 Gbs
