Cisco UCS 5108 Blade Server Chassis
SUPPLEMENTAL MATERIAL
37
Supported 2-CPU card adapter combinations are shown in Table 20.
The general connectivity diagrams between the card adapters and the different fabric extenders are shown
in
Figure 21 on page 38 through Figure 23 on page 39.
Table 20 Supported Mezzanine Adapter Combinations (2-CPU Configuration)
Adapter in VIC
1240 Connector
Adapter in
Mezzanine
Slot 1
Adapter in
Mezzanine Slot 2
Total Available Bandwidth
1
1. Cisco-designed adapters are capable of port channeling. A port channel bundles up to four individual
interfaces into a group to provide increased bandwidth and redundancy. Port channeling also load balances
traffic across these physical interfaces. The port channel stays operational as long as at least one physical
interface within the port channel is operational. Cisco-certified adapters suppled by third-party vendors do
not support port channeling. Port channeling is indicated with an oval drawn around several individual ports.
2 x 2208XP 2 x 2204 XP 2 x 2104 XP
VIC 1240 Not populated Not populated 40 Gb 20 Gb 20 Gb
VIC 1240 Not populated VIC 1280 120 Gb 60 Gb 40 Gb
VIC 1240 Not populated Cisco-certified
mezzanine adapter
2
2. Cisco-certified mezzanine adapters are manufactured by third-party vendors and are certified by Cisco for use
in the servers. For more information about supported Cisco-certified mezzanine adapters, see
http://www.cisco.com/en/US/docs/unified_computing/ucs/hw/chassis/install/blade.html#wp1010426
60 Gb 40 Gb 40 Gb
VIC 1240 Port Expander
Card for VIC
1240
3
3. Only the Port Expander for VIC 1240 is functional in mezzanine slot 1 in 2-CPU configurations
Not populated 80 Gb 40 Gb
Not supported
4
4. The 2104XP fabric extender is not compatible with any adapter installed in mezzanine slot 1
Not populated Not populated Cisco-certified
mezzanine adapter
20 Gb 20 Gb 20 Gb
VIC 1240 Port Expander
Card for VIC
1240
3
VIC 1280 160 Gb 80 Gb
Not supported
4
