Cisco UCS 5108 Spec Sheet

Cisco UCS 5108 Blade Server Chassis
TECHNICAL SPECIFICATIONS
45
Efficiency
(80Plus Gold Certified)
10% load 20% load 50% load 100% load
88.61% 91.64% 92.21% 90.97%
Input Connector IEC320 C20
Table 24 DC Input Platinum Power Supply (UCSB-PSU-2500ACDV) Specifications
Description Specification
DC-input voltage 200 to 380 VDC nominal (Range: 180 to 400 VDC)
Maxumum DC-input current 15.5 Amps @ 200 VAC
Maximum Input power
Maximum output power per
power supply
2500 W
Maximum inrush current 35 A (sub cycle duration)
Maximum hold up time 12 ms @ 2500 W
Power supply output
voltage
12 VDC
Efficiency rating Climate Savers Platinum
Efficiency 10% load 20% load 50% load 100% load
Input Connector
Table 25 AC Input Platinum Power Supply (UCSB-PSU-2500ACPL) Specifications
Description Specification
AC-input voltage 200 to 240 VAC nominal (Range: 180 to 264 VAC)
AC-input frequency 50 to 60 Hz nominal (Range: 47 to 63 Hz)
AC-input current < 16 Amps @ 200 VAC
Maximum Input VA 2790 VA @ 200 VAC
Maximum output power
per power supply
2500 W @ 200 to 240 VAC (up to four power supplies)
Maximum inrush current 35 A (sub cycle duration)
Table 23 AC Input Gold Power Supply (N20-PAC5-2500W) Specifications (continued)
Description Specification

Cisco UCS 5108 Specifications

General

Number of Blade Slots	8
I/O Module Bays	2
Supported Blade Servers	Cisco UCS B-Series Blade Servers
Power Supply Options	Up to four hot-swappable power supplies (AC or DC)
Cooling	Redundant hot-swappable fans
Management	Cisco UCS Manager
Blade Slots	8
Fabric Interconnects	Cisco UCS 6100 or 6200 Series
Power Supplies	Up to 4 hot-pluggable power supplies
Form Factor	6RU rack-mountable
