Cisco UCS B200 M3 Blade Server
14
CONFIGURING the SERVER
Supported Configurations
(1) B200 M3 configured with 1 CPU without memory mirroring
■ Select from 1 to 12 DIMMs for CPU 1 (note that there are 12 DIMM slots available)
(2) B200 M3 configured with 1 CPU with memory mirroring
■ Select 2, 4, 6, 8, or 12 DIMMs for CPU 1. The DIMMs will be placed by the factory as shown in
Table 5:
■ Select the memory mirroring option (N01-MMIRROR) as shown in Table 4 on page 13.
Table 5 DIMM Placement With Memory Mirroring (B200 M3 configured with 1 CPU)
Number of DIMMs
per CPU
DIMM Placement in Banks (with memory mirroring implemented)
CPU 1
2 2 DIMMs in Bank 0 (A0, B0)
4 4 DIMMs in Bank 0 (A0, B0, C0, D0)
6
1
Notes...
1. Not recommended (for performance reasons)
3 DIMMs in Bank 0 (A0, B0, C0)
3 DIMMs in Bank 1 (A1, B1, C1)
8 4 DIMMs in Bank 0 (A0, B0, C0, D0)
4 DIMMs in Bank 1 (A1, B1, C1, D1)
12 4 DIMMs in Bank 0 (A0, B0, C0, D0)
4 DIMMs in Bank 1 (A1, B1, C1, D1)
4 DIMMs in Bank 3 (A2, B2, C2, D2)
