Citizen CL-S700DT

Appendixes
50
Specications
Item Description
Printing Printing method Thermal transfer/Direct thermal
Resolution Main scanning line density: 203 dots/inch (8 dots/mm)
Sub- scanning line density: 203 dots/inch (8 dots/mm)
Head 864 dots (printable dots: 832 dots)
Max. print width 104 mm 4.1 inch
Max. print length 812.8 mm 32 inch
Print density Print density is adjustable with software
Printing speed Printing speed setting 2 - 7 inches per second
Print mode Batch mode Normal printing (single or multiple sheets)
Tearomode Feedsbackmediatothetear-opositionafterprintingiscompleted.
Cut mode
*1
Prints while cutting at designated sheet units.
The following two kinds of cut mode operations are done.
•Backfeed
•Cutthrough
(Cut through refers to stopping part-way through printing the "next
label" to make the cut. After cutting, printing restarts but there is a
chance of a small gap or mark at the temporary stop position.)
Peel mode
*2
Peels labels from the liners after printing them.
Media Types of media Roll, fanfold
(continuous media, die-cuts, continuous tags. paper or tickets)
Recommended media Direct thermal media: label media (150LA-1 Ricoh), tag media
(TB2E0V, Mitsubishi Paper)
Max. media width 118.0 mm 4.65 inch
Min. media width 25.4 mm 1.00 inch
Min. label width 7.62 mm 0.30 inch
Min. label pitch
*3
6.35 mm 0.25 inch
Max. media thickness 0.254 mm 0.01 inch
Max. media length 812.8 mm 32 inch
Min. media length 6.35 mm 0.25 inch
Min. media thickness 0.0635 mm 0.0025 inch
On-board roll media
diameter
Max. outside diameter: 203mm 8 inch
Media core: 38 to 76 mm 1.5 to 3 inch
Bar code
(for Datamax® emulation)
One-dimension •Code3of9•UPC-A•UPC-E•EAN-13(JAN-13)
•EAN-8(JAN-8)•Interleaved2of5•Code128
•HIBC(Modulus43-usedcode3of9)•Codabar(NW-7)
•Int2of5(Modulus10-usedInterleaved2of5)•Plessey
•CaseCode•UPC2DIGADD•UPC5DIGADD
•Code93•Telepen•ZIP•UCC/EAN128
•UCC/EAN128(forK-MART)
•UCC/EAN128RandomWeight•FIM
Two-dimension UPS Maxi Code, PDF-417, Data Matrix, QR Code, Aztec, RSS
Bar code
(for Zebra® emulation)
One-dimension •Code11•Interleaved2of5•Code39•EAN-8•UPC-E•Code93
•Code128•EAN-13•Industrial2of5•Standard2of5
•ANSICODABAR•LOGMARS•MSI•Plessey•UPC/EANExtensions
•UPC-A•POSTNET•Planet
Two-dimension •Code49•PDF-417•CODABLOCK•UPSMaxiCode
•MicroPDF-417•DataMatrix•QRCode•RSS•TLC39
Font
(for Datamax® emulation)
1. Seven kinds of xed pitch font
 •Overseas,EnglishfontsandEuropeanfonts
2. OCR fonts OCR-A
*4
, OCR-B
*4
3. Proportional fonts
CG Triumvirate smooth font
CG Triumvirate Bold smooth font
(6, 8, 10, 12, 14, 18, 24, 30, 36, 48 points)
 •Characterset:Conformswithcodepage850standards
4. True type™ rasterizer
*5
