Citrix ADC MPX
Power Supply 960 W AC 960 W DC
Power supply is functional
(Power ON)
GREEN GREEN
Power supply failure ‑ ‑
Warning
(OVP/UVP/OCP/OTP/Fan)
‑ ‑
Note
Power Supply Unit ON‑Green
Power Supply Unit OFF‑ No Color
There is no other function other than ON or OFF for the module LEDs. A continuous beep sound
occurs if a cable or module is unplugged.
Flex power supply
The Flex power supply is used on the following platforms:
• 750 W AC/DC
– MPX 24000
– MPX 22000
– T1200
Flex (750 W) power supply LED behavior
Power Supply 750 W AC 750 W DC
LED behavior when F750E‑XX A00
No Power to any power
supply
O O
No power to this power
supply
LED goes o LED goes o
Power supply is in standby
mode
‑ ‑
Power supply is functional
(Power On)
GREEN GREEN
Power supply failure ‑ ‑
