Citrix ADC MPX
stalled.
To silencethe alarm, press the small red button on the back panel of the appliance. The Disable alarm
button is functional only when the appliance has two power supplies.
Replace a DC power supply
Most Citrix ADC MPX platforms can accommodate two power supplies. Some platforms can accom‑
modate four power supplies. All Citrix ADC appliances function properly with a single power supply,
except the appliances that can accommodate four power supplies. These appliances need two power
supplies for proper operation. The other power supply serves as a backup. All power supplies must
be of the same type (AC or DC).
Note: If the appliance has only one power supply, you have to shut down the appliance before replac‑
ing the power supply. With two power supplies, you can replace one power supply without shutting
down the appliance, provided the otherpowersupply is working. With four power supplies, you can re‑
place one or two power supplies without shutting down the appliance, provided the other two power
supplies are working.
To install or replace a DC power supply on a Citrix ADC appliance:
1. Loosen the thumbscrew and press the lever towards the handle and pull out the existing power
supply, as shown in the following figure.
Note: The illustration in the following figures might not represent the actual Citrix ADC appli‑
ance.
Figure 2. Remove the existing DC power supply
2. Carefully remove the new power supply from its box.
3. On the back of the appliance, align the power supply with the power supply slot.
4. Insert the power supply into the slot while pressing the lever towards the handle. Apply firm
pressure to insert the power supply firmly into the slot.
Figure 3. Inserting the Replacement DC Power Supply
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 110
