CITROEN C2 - Special Features: Clutch Tightening Torques

149
CLUTCH
GEARBOX
TRANSMISSION
SPECIAL FEATURES: CLUTCH TIGHTENING TORQUES
Clutch
1 Screws for clutch plate / flywheel 2 ± 0,2
2
Screw for gasket plate at flywheel end / crankshaft
(TU and ET3 engines)
6,7 ± 0,6
Flywheel / crankshaft (DV engine)
3 Pre-tightening 1,7 ± 0,2
Angular tightening 70°±5°
Sequence for tightening the flywheel screws
B1DP1LXC
B1CP0H9C
C3
B2BP06DC
