CITROEN C2 - Brake Specifications (with Abs Ref)

Engines HFX KFV
KFU
NFU NFS 8HX 8HZ 8HY 9HX
KFU (*)
Master cylinder 22,2 (**)
Ø Master vac 228,6
mm Caliper makes/ LUCAS/TRW LUCAS/TRW LUCAS/TRW LUCAS/TRW
pistons C 48/13 48 C 54/22 54 C 48/13 48 C 54/22 54
Disc Plain 266 266
FT Disc thickness/min. thickness 13/11 13/11
Ø
mm
Disc Ventilated 266 266
Disc thickness/min. thickness 22/20 22/20
Brake pad supplier/grade TEXTAR T 4144
Ø Cylinder or caliper LUCAS C38 HR 9/13/38
mm Disc Plain 247 247
RR Disc thickness/min. thickness 9/7 9/7
Ø Drum/max. thickness 203/205/
mm Width
203/205/38 203/205/38
38
Make DON GALFER DON DON (***) DON
Brake lining grade 8259 G 4554 8259 8259(***) 8259
230
BRAKES
BRAKE SPECIFICATIONS (WITH ABS REF)
With ABS REF: Braking compensator integral to the wheel cylinder on vehicles with ABS REF all engine-types. The main brake compensator and limiter
functions are assured by the ABS REF system.
(***) = RPO

9898.

9898 = GALFER/ G 4554. (*) = STT = Stop and start. (**) = With emergency braking system (AFU).
