CITROEN C2 - Suspension

196
AXLES
SUSPENSION
STEERING
SUSPENSION
Front axle
(1) Nut fixing suspension leg on body : 6,5 ± 0,6
(2) Damper
(16) Cup
(17) Damper nut : 6,5 ± 0,6
(18) Damper cup
(19) Ball bearing
(20) Spring thrust cup
(21) Travel stop cup
(22) Suspension spring
(23) Damper rod protector
(24) Travel stop
B3BP180D
