64
ENGINE
SPECIAL FEATURES - TIGHTENING TORQUES (m.daN)
Cylinder block
Coolant pump
14 Pre-tightening 0,3 ± 0,1
Tightening 0,9 ± 0,1
Con rod screws
15 Pre-tightening 1 ± 0,1
Angular tightening 100°±5°
Flywheel (according to equipment)
16 Pre-tightening 1,7 ± 0,2
Angular tightening 75°±5°
Clutch mechanism 2 ± 0,2
Engine: 9HX
B1DP1LKP
B1CP0GKC
(16) Sequence for tightening the flywheel screws
