ci5000 Series Printer Operation Guide
Version 1.0 4-10
High Voltage Trip the deflection plates are shorted or dirty
1. Ensure the Deflection Plates are clean
and dry.
2. Watch for Ink buildup due to lack of
grounding.
3. Check the Jet alignment.
4. Contact your local Service Technician
Modulation Error no ink droplets have been detected
1. Check for any tripped fuses.
2. Ensure that Printhead components
are clean and dry.
3. Contact your local Service Technician
High Viscosity Error Ink thickness is too high
1. Ensure all the Fill caps are on tight.
2. Ensure the Make-up Tank has the
appropriate Make-up in it.
3. Contact your local Service Technician
1. Contact your local Service Technician
Error
ball movement is not detected in the
viscometer
1. Contact your local Service Technician
Gutter (poor
vacuum)
ink pooling or dripping from the gutter in
the printhead
1. Check that the Gutter is not blocked
2. Contact your local Service Technician
Fault / Issue 故障 Description of Fault 故障描述
Possible Cause / Fix 可能的原因/处理
方法
No Power 没有电
When the Power Button is pushed the
printer does not turn on 当按下电源按钮
时，喷码机没有通电打开
1. Check the power to the unit.检查外
部电源
2. Check LED22 on CPU board.检查主板
上的 LED22
3. the Power Switch.检查电源开关
4. Check the Mains Fuses.检查主保险
丝
5. Contact your local Service Technician
联系当地技术维修人员
Power on – No
Display or Display
Rolling 通电-没有显
示或显示内容滚动
The CPU Board is powered up but screen is
not visually booting 主板有电但是显示器
没有完成初始化
1. Check the flat ribbon cable
connection to the J7 connector of the
CPU board.检查连接到主板 J7 插头的
排线
2. Contact your local Service Technician
联系当地技术维修人员
Pressure High Error
压力过高报警
Pump running at over 120rps 泵转速超过
120rps
1. Check Return Line to Ink Tank for
clogs.检查回到分配块的管路是否堵塞
2. Contact your local Service Technician
联系当地技术维修人员
To Next Page
