SM-A20758-A/3 1. PRODUCT OVERVIEW
11 2020-10-06
◼ EVD-3100-C (maximum pressure:100kPa)
EVD-3100- C [*2] [*3]- [*4] [*5]-3
Clean compressed air (equivalent to ISO Class 1. 3. 2)
24 VDC ± 10% (stabilized power supply with ripple rate of 1% or less)
0.15 A or less (starting current is 0.6 A or less when the power is turned on)
(Port type A)
3-digit 7-segment LED,
display accuracy: ±2%FS or less
1 kPa to 100 kPa
(min. set width 1 kPa/set resolution 1 kPa)
Temperature
characteristics
[*2] =08 Rc1/4, [*2] =10 Rc3/8
[*2] =08G G1/4, [*2] =10G G3/8
[*2] =08N NPT1/4, [*2] =10N NPT3/8
[*2]=08,10 Rc3/8
[*2]=08G,10G G3/8
[*2]=08N,10N NPT3/8
Without Unit change function
Unit change kPa / psi / bar (Accessory ： Unit label sticker psi / bar)
Power reverse connection protection
Note 1: There is 1%FS or less residual pressure (1 kPa or less) when the input signal is 0%.
Note 2: Use the power supply unit that have the power supply ability sufficiently to each port of IO-Link master.
Note 3: The above characteristics are based on the condition that power supply voltage is 24 VDC ± 0.1 VDC, working pressure
is set to maximum control pressure +50 kPa, and control pressure is 10% to 90% (with no load, ambient temperature of
25°C ± 3°C).
Also, the specified values are only for when the secondary side is a closed circuit and pressure fluctuations will occur if
the product is used for blowing or similar applications.
Note 4: The above characteristics are based on the condition that working pressure and control pressure are set to their maximum.
Note 5: The above characteristics are based on the condition that working pressure is set to maximum and the step amount is
changed from 50%F.S.→100%F.S.
50%F.S.→60%F.S.
50%F.S.→40%F.S.
Note 6: KA type is only available outside Japan.
To Next Page
