SM-A20758-A/3 1. PRODUCT OVERVIEW
22 2020-10-06
Dimensions
◼ EVD-1000 Series
M12,4pin connector
φ4.2 Port R
(Pilot air exhaust
port)
2-（Select by port diameter）
08
Rc1/4
08G
G1/4
08N
NPT1/4
4-M3 depth6
φ5.3 EXH port
