SM-A20758-A/3 1. PRODUCT OVERVIEW
6 2020-10-06
Model Number Indication
EVD-1000 Series
*Symbol
d
KA type is only available outside Japan.
EVD-1 - - -
Symbol
Description
Pressure specification
100
100kPa
500
500kPa
900
900kPa
Input specification
C
IO-Link
Port size
08
Rc1/4
08G
G1/4
08N
NPT1/4
Unit change
Blank
Unit change none
KA
Unit change available
Option
Cable option
Blank
None
MS
IO-Link
M12 straight(female)
/M12 straight(male), 3m
ML
IO-Link
M12 L type(female)
/M12 straight(male), 3m
MM
IO-Link
M12 One side straight
(female), 3m
Bracket option
Blank
None
B1
B-type bracket, floor mounted
L1
L-type bracket, wall mounted
Power supply voltage
3
24 VDC
a
m
eb
a
b
c
d
e
f
3
500
08
KA
MS
C
Unit change
d
Port size
c
Input specification
b
Pressure specification
a
Option
e
Power supply
voltage
f
