Clack WS CI Series User Manual

12
3.3 Crystal Right 100.
Clack CI Valves Set up as SIMPLEX CR100.
All figures based on a calculated hardness of 100ppm using CR100 Crystal-Right
Please apply the settings in the following sequence
Selections are made using the UP & DOWN buttons until the required setting is displayed,
After each setting press NEXT to continue or press REGEN to go back one stage.
Vessel Size 1044 1054 1252 1354 1465 1665 1865 2160 2469 3072 3672
Media Volume (cft) 1 1.5 2 3 4 5 6 7 11 19 24
Valve Size 1" 1" 1" 1" 1" 1" 1" 2" 2" 2" 2"
Step 1, Cycle Sequence,
Press NEXT and DOWN simultaneously for 3 seconds and release.
Screen will display SOFTENING flashing
Press NEXT and DOWN simultaneously for three seconds, the screen should display SET 1, adjust to turbine setting below,
Set 1.0 1.0 1.0 1.0 1.0 1.0 1.0 2 2 2 2
Set (Alternating)
SET dp
Hardness
Set 1
Set 2
Set 3
Set 4
Set 5
Step 2. System Setup,
Press NEXT and DOWN simultaneously for 3 seconds and release.
SET with SOFTENING flashing should appear on screen.
Cycle 1 Backwash 5 5 5 5 5 5 5 5 5 5 5
Cycle 2 Brine dn 66 52 64 57 81 67 75 55 61 49 67
Cycle 3 Rinse 7 7 7 7 7 7 7 7 7 7 7
Cycle 4 Fill Kg 4 5 6.8 8.5 12 15.25 20.5 23.75 37.5 64.5 81.5
Cycle 4 Fill Mins 2" Only 9 14
12 (4.2g) 12 (5.3g)
Cycle 5
Set Capacity Kg 0.7 1.3 1.7 2.1 3 3.8 5.1 5.9 9.3 16.1 22.3
Set Regen
Set Time Regen
Set rLY 1 (Relay 1)
Set rLY 2 ( Relay 2)
Set Salt
Step 3, Display Settings.
Press NEXT & UP simultaneously for three seconds and release.
HARDNESS with 340 flashing should appear on screen,
Hardness
Hardness 2
Regen Day
Set Time Regen Hrs
Set Time Regen Min
Step 4, Set time of day,
Press SET CLOCK
Set hours using the up and down buttons.
Set minutes using the up and down buttons,
Calculation.
Hardness is calculated as follows: 1 x CaCO3 ppm + 2 x Na ppm + Fe ppm + Mn ppm
19/12/2018
End
Software version from 332.2
An additional screen will now show if 1.5 or 2 has been selected. Select " FLo1.5 for 1.5" or FLo2 for 2" valve"
Alt Off
or (see note 1 for options)
Off
or (see note 2 for options)
PPM
Backwash
Brine dn
Rinse
Fill
Off
or (see note 6 for options)
Off
or (See note 7 for use)
Normal
or (See note 4 for options)
Off
or (see note 5 for options)
If 1.5 has been selected above an extra screen will show (Fill) select Kg
5
2:
:00
Set on site (See calculation below)
NA
Auto (Automatic reserve calculation)
or (See note 3 for options)
