Clack CI Valves Set up as SIMPLEX Nitrate Software version from 332.2
Capacities based on 20g No3 removal per litre of resin,
Please apply the settings in the following sequence
Selections are made using the UP & DOWN buttons until the required setting is displayed,
After each setting press NEXT to continue or press REGEN to go back one stage.
Vessel Size 735 822 835 935 1035 1044 1054
1248/52
1354 1465 1665 1865 2160 2469 3072 3672 4278
Swan
Swan Swan Swan
Media Volume (litres) 18 22 25 30 35 35 42 50 75 100 150 200 250 350 500 700 1000
Valve Size 1" 1" 1" 1" 1" 1" 1" 1" 1" 1" 1" 1" 1.5" 2" 2" 2" 2"
Step 1, Cycle Sequence,
Press NEXT and DOWN simultaneously for 3 seconds and release.
Screen will display SOFTENING flashing
Press NEXT and DOWN simultaneously for three seconds, the screen should display SET 1, adjust to turbine setting below,
Set 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.5 2 2 2 2
Set (Alternating)
SET dp
Hardness
Set 1
Set 2
Set 3
Set 4
Set 5
Step 2. System Setup,
Press NEXT and DOWN simultaneously for 3 seconds and release.
SET with SOFTENING flashing should appear on screen.
Cycle 1 Backwash 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
Cycle 2 Brine dn 64 59 59 63 63 60 70 62 64 86 71 84 68 66 81 72 72
Cycle 3 Rinse 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
Cycle 4 Fill Kg 3.05 3.7 4.3 5.1 5.1 6.05 7.1 5.5 12.8 17 25.5 34 42.5
Cycle 4 Fill Mins 2" Only
11 (4.2g) 16 (4.2g) 18 (5.3g) 25 (5.3g)
Cycle 5
Set Capacity Kg 0.36 0.44 0.5 0.6 0.7 0.7 0.84 1 1.5 2 3 4 5 7 10 14 20
Set Time Regen
Set rLY 1 (Relay 1)
Set rLY 2 ( Relay 2)
Set Salt
Step 3, Display Settings.
Press NEXT & UP simultaneously for three seconds and release.
HARDNESS with 340 flashing should appear on screen,
Hardness
Hardness 2
Regen Day
Set Time Regen Hrs
Set Time Regen Min
Step 4, Set time of day,
Press SET CLOCK
Set hours using the up and down buttons.
Set minutes using the up and down buttons,
Note:
See note below for information
An additional screen will now show if 1.5 or 2 has been selected. Select " FLo1.5 for 1.5" or FLo2 for 2" valve"
or (see note 4 for options)
or (see note 1 for options)
or (see note 2 for options)
or (see note 3 for options)
If 1.5 has been selected above an extra screen will show (Fill) select Kg
Entering the Nitrate level as PPM will provide a volumetric capacity of the system, if you need to increase the
capacity you can lower the PPM setting or increase the PPM setting to reduce capacity.
or (see note 5 for options)
or (see note 6 for options)
If a Time version set to 3, if Metered set to 14
Set on Site using the Nitrate reading in ppm "if SET REGEN is set to AUTO"
Auto for Metered (Enter Nitrate level as PPM)
To Next Page
