Clack WS1 Series User Manual

WS1”, 1.5” & 2” Series Watersoftener
Installation Operation Maintenance Manual
SIMPWS1 REV3 13/07/11 PAGE 22 OF27
11.2.2 WS1 100-350 L
PARAMETER UNITS 100L 120L 150L 250L 350L
VESSEL SIZE INCH 14x65 14x65 16x65 21x62 24x72
BRINE TANK
HEIGHT
MM 1040 1040 950 900 1100
BRINE TANK WIDTH MM 480 480 700 840 880
TOTAL HEIGHT MM 1984 1984 1988 2038 2225
REAR CLEARENCE
REQUIRED
MM 50 50 50 50 50
INLET CONNS INCH 1 1 1 1 1
OUTLET CONNS INCH 1 1 1 1 1
DRAIN CONNS INCH ¾ ¾ ¾ ¾ ¾
BREIN TANK
OVERFLOW
INCH ½ ½ ½ ½ ½
DELIVERED
WEIGHT
KG 115 130 170 280 380
ELECTRICAL
POWER 240 V 50 HZ
V/A 1.2 1.2 1.2 1.2 1.2
IMPORTANT NOTES
MAXIMUM OPERATING PRESSURE 5.5 BARG MINIMIUM OPERATING PRESSURE 1.7 BARG
HEADROOM ALLOW 100MM GREATER THAN THE OVERALL HEIGHT.

Clack WS1 Series Specifications

General

Series	WS1
Regeneration	Upflow
Certifications	NSF/ANSI 44
Operating Temperature	34 - 120°F (1 - 49°C)
Power Supply	12 VAC
Type	Water Softener
