Clack WS1 Series User Manual

WS1”, 1.5” & 2” Series Watersoftener
Installation Operation Maintenance Manual
SIMPWS1 REV3 13/07/11 PAGE 24 OF27
11.2.4 WS2 150-750 L
PARAMETER UNITS 150 200 250 300 350 500 750
VESSEL SIZE INCH 16x65 21x62 21x62 24x72 24x72 30x72 36x72
BRINE TANK
HEIGHT
MM 950 900 1100 1100 1250 1250 1330
BRINE TANK
WIDTH
MM 700 840 880 880 960 960 1050
TOTAL
HEIGHT
MM 2098 2098 2098 2335 2335 2560 2633
REAR
CLEARENCE
REQUIRED
MM 50 50 50 50 50 50 50
INLET CONNS INCH 2 2 2 2 2 2 2
OUTLET
CONNS
INCH 2 2 2 2 2 2 2
DRAIN
CONNS
INCH 1 1 1 1 1 1 1
BREIN TANK
OVERFLOW
INCH ½ ½ ½ ½ ½ ½ ½
DELIVERED
WEIGHT
KG 170 220 280 330 380 500 750
ELECTRICAL
POWER 240 V
50 HZ
V/A 1.2 1.2 1.2 1.2 1.2 1.2 1.2
IMPORTANT NOTES
MAXIMUM OPERATING PRESSURE 5.5 BARG MINIMIUM OPERATING PRESSURE 1.7 BARG
HEADROOM ALLOW 100MM GREATER THAN THE OVERALL HEIGHT.

Clack WS1 Series Specifications

General

Series	WS1
Regeneration	Upflow
Certifications	NSF/ANSI 44
Operating Temperature	34 - 120°F (1 - 49°C)
Power Supply	12 VAC
Type	Water Softener
