Nitrogen Generator NiGen HF - NiGen LCMS
15
5.2.
Pneumatic connections
5.2.1.
Nitrogen outlet
m
The distribution line must be made of pipe rated for a pressure of at
least 10.5 bar (152 psi).
The pipe diameter must be sized on the basis of the acceptable pressure drop
values of the utility. Pipelines with an internal diameter of at least 8mm are rec-
ommended (e.g. polyamide pipe 10x8 mm).
e
To ensure nominal purity of the delivered nitrogen is maintained (minimize con-
tamination from oil residue, dust, scaling and humidity), it is recommended to
use clean and/or treated pipelines for final gas distribution.
CONNECTION
• Locate the nitrogen coupling, marked “NITROGEN OUTLET” at the rear of the
generator.
• Connect the line.
5.2.2.
Air outlet
Not applicable to NiGen HF-0, NiGen LCMS 40-0 and NiGen LCMS 100
m
The distribution line must be made of pipe rated for a pressure of at
least 10.5 bar (152 psi).
CONNECTION
• Locate the compressed air coupling, marked “AIR OUTLET” at the rear of the
generator.
• Connect the line.
e
The outlet air pressure is adjustable from 0 to 8 bar
e
The available outlet air flow depends on the nitrogen consumption. Please refer
to the following tables
