Claind NiGen LCMS - Air Inlet Connection

Installation
16
LCMS 40-1
HF1
5.2.3. Air inlet
not applicable to NiGen HF-1 and NiGen LCMS 40-1
CONNECTION
• Locate the compressed air coupling, marked “AIR INLET” at the rear of the gen-
erator.
• Connect the line.
m The compressed air supply to the generator may not exceed 10.5 bar
(152 psi).
Nitrogen
outlet flow
[Nl/min]
Max available
air outlet flow
[Nl/min]
0 - stand-by 75
10 30
20 20
30 10
40 0
Nitrogen
outlet flow
[Nl/min]
Max available
air outlet flow
[Nl/min]
0 - stand-by 75
Production 14
