Description of the generator
6
3. Description of the generator
3.1. Equipment supplied
Unless otherwise agreed, the forniture includes:
• n°1 nitrogen generator;
• n°1 CD user’s manual;
• n°1 applicable declarations of conformity of tank and safety valve;
• n°1 cable for the electrical mains;
• n°1 fitting for plastic tube external diameter 4mm;
• n°1 fitting for plastic tube external diameter 6mm;
• n°1 fitting for plastic tube external diameter 10mm;
• 2 mt of plastic tube external diameter 4mm;
only for generator NiGen HF the forniture includes:
• n°1 brass fitting for copper tube external diameter1/4”.
3.2. Technical specifications
3.2.1. Nitrogen
(*) the flow rate is given at 20°C and 1 atm
(**) purity referred to residual oxygen
3.2.2. Compressed air supply table
NiGen LCMS 40-1 and HF-1 produce nitrogen and compressed air.
This table shows on X axes the nitrogen product, and on Y axes the compressed
air available only for the model LCMS 40-1.
Max flow rate (*)
NiGen HF-0 6 Nl/min 6 slpm
NiGen HF-1 6 Nl/min 6 slpm
NiGen LCMS 40-0 40 Nl/min 40 slpm
NiGen LCMS 40-1 40 Nl/min 40 slpm
NiGen LCMS 100 100 Nl/min 100 slpm
Pressure
settable from 0 to
7 bar
settable from 0 to
100 psi
Purity (**)
NiGen HF up to 99.9995 %
NiGen LCMS up to 99.9 %
