Nitrogen Generator NiGen HF - NiGen LCMS
27
• pull down the pressure regulator knob to release it
set the pressure by turning the knob clockwise to increase, counterclockwise to
decrease it. To visualize the outlet pressure,
par. 7.8
..
7.9.2.
Adjusting the air outlet pressure
Only for NiGen HF-1 and NiGen LCMS 40-1
e
the pressure can be adjusted from 0 to 8 bar ( from 0 to 116 psi)
• remove the front panel
• identify the air outlet pressure regulator at the top left
• pull down the pressure regulator knob to release it
set the pressure by turning the knob clockwise to increase, counterclockwise to
decrease it.
