7. SPECIFICATIONS
FM Tuner with RDS
Frequency Range: USA 87.9 ~ 107.9MHz (0.2MHz STEP)
Europe 87.5 ~ 108.0MHz (0.05MHz STEP)
Australia 87.5 ~ 108.0MHz (0.01MHz STEP)
Other Countries 87.5 ~ 108.0MHz (0.01MHz STEP)
AM Tuner
Frequency Range: USA 530 ~ 1710kHz (10kHz STEP)
Europe 531 ~ 1602kHz (9kHz STEP)
Australia 531 ~ 1629kHz (9kHz STEP)
Other Countries 531 ~ 1629kHz (9kHz STEP)
Weather Band with RDS (if available)
NOAA Frequency Range: 162.400MHz ~ 162.550MHz
Channel 1: 162.400MHz Channel 2: 162.425MHz Channel 3: 162.450MHz
Channel 4: 162.475MHz Channel 5: 162.500MHz Channel 6: 162.525MHz
Channel 7: 162.550MHz
Audio
Maximum Power Output: 50W x 4
Rated Power Output: 21W x 4 (CEA2006) 1% THD, 1 kHz @ 14.4V
High Pass Filter (Front/Rear): 70/105/140/THROUGH (Speaker and RCA) Low Pass Filer (Subwoofer):
50/75/100/THROUGH
BASS Control: 50Hz Frequency, +14dB ~ -14dB
MID Control: 1k Frequency, +14dB ~ -14dB
TREBLE Control: 12kHz Frequency, +12dB ~ -12dB
General
Power Supply Voltage: 14.4VDC (10.8 to 15.6V allowable)
Grounding System: Negative Ground
Speaker Impedance: 4-8 ohms per channel
Processor: Freescale iMx287 ARM9 454MHz 2GB RAM
ASTM B117 (Salt/Fog Exposure) = Black Box and Controller
ASTM D4329 (UV Exposure) = Black Box and Controller
IP66 (Black Box)
IP67 (Controller)
Dimensions:
Black Box = 2” (H) x 8” (W) x 7” (L)
Controller = 4” (H) x 6” (W) x 1” (D)
Heat Sink: Magnesium/Aluminum
Supported Audio Formats
USB: MP3 and WMA
SAE J1939
Broadcast Type: Open Broadcast 29 Bit
Bandwidth: 500KB/Second
Clock: 1MB/Second
Display Controller
LCD: 4.3” Optically Bonded Color
Resolution: 480 x 272
Luminance: 650 NITS
NOTE:
Specifications and Design are subject to change Without notice for further improvement.
INSTALLATION AND WIRE CONNECTIONS
Contents
1. BEFORE STARTING
2. PACKAGE CONTENTS
3. INSTALLATION CAUTIONS
4. BLACK BOX INSTALLATION
5. DISPLAY CONTROLLER INSTALLATION
6. WIRE CONNECTIONS
1. BEFORE STARTING
1. Read these instructions carefully
2. This unit has been developed exclusively for use in vessels With a negative ground 12V power (batte r y/
charging system) source.
3. Be sure to disconnect the batte r y (-) Negative terminal before sta r ting.
This is to prevent sho r t circuits during the installation process. (Figure 1)
2. PACKAGE CONTENTS
Item Quantity
1. CMS5 Black Box .......................................................................................................... 1
2. CMS5 Display Controller ............................................................................................. 1
3. 34-Pin Keyed Power/Speaker/RCA Connector/SWI .................................................... 1
4. 26-Pin Keyed Remote/USB1, 2/Wired Remote (MW1,MW2)/
Wired Remote (MW4)/ Display Controller Connector .................................................. 1
5. 34-Pin Keyed AUX/SXM/BT Microphone/Video/J1939 ................................................ 1
6. C A T5 Ethernet Display Controller Cable (10-feet) ....................................................... 1
7 Metal Display Controller Mounting Bracket .................................................................. 1
8. Stainless Steel Metric Threaded Studs (M4-.7 @ 4mm-.7 x 38mm) (Controller) ........ 2
9. Stainless Steel Metric Lock Washer (5mm) for Controller ........................................... 2
10. Stainless Steel Metric Flanged HEX Nuts (M4-.7 @ 4mm-.7) (Controller) .................. 2
11. Stainless Steel Metric Self T apping Screw (M4) for Mounting Black Box .................... 4
12. CMS5 Owner’s Manual (English/French/Spanish) - CD .............................................. 1
13. CMS5 Installation Guide (English) - Printed ................................................................ 1
14. CMS5 Installation Guide (French) - On Owner’s Manual CD ...................................... 1
15. CMS5 Installation Guide (Spanish) - On Owner’s Manual CD .................................... 1
16. CMS5 Quick Sta r t Guide (English) - Printed ................................................................ 1
17. CMS5 Quick Sta r t Guide (French) - On Owner’s Manual CD ...................................... 1
18. CMS5 Quick Sta r t Guide (Spanish) - On Owner’s Manual CD .................................... 1
3. INSTALLATION CAUTIONS
1. In order to avoid any interference, do not install the Black Box or Display Controller in the Proximity of the
engine compa r tment.
2. The use of unauthorized pa r ts can cause permanent damage to the unit.
3. Always check your wire connections to ensure proper installation before turning the unit ON.
4. Consult with your nearest dealer for proper installation or if common pa r ts are needed.
* Seek professional assistance if modifications or drilling holes in the vessel are needed.
5. Do not install the system where it will be subjected to excessive moisture, dust, di r t, foreign pa r ticles or
vibration. Areas of high temperature from the engine, direct sunlight, heater or hot Air should be avoided.
6. Do not install the system in a location where it will interfere with the vessels operation, or it will injure the
passengers if there is a sudden or emergency stop.
