MAX973HD
English
INSTALLATION AND WIRE
CONNECTION MANUAL
Package Contents
1 Main unit. . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 GPS antenna . . . . . . . . . . . . . . . . . . . . . . . 1
3 Power supply lead . . . . . . . . . . . . . . . . . . . 1
4 Vehicle signal lead . . . . . . . . . . . . . . . . . . 1
5 RCA pin lead . . . . . . . . . . . . . . . . . . . . . . . 1
6 Microphone for voice control . . . . . . . . . . 1
7 Microphone extension lead . . . . . . . . . . . 1
8 Accessory bag (No. 1). . . . . . . . . . . . . . . . 1
9 Accessory bag (No. 2). . . . . . . . . . . . . . . . 1
0 Owner’s Manual (this book) . . . . . . . . . . . 1
! Navigation System Operation Manual . . . 1
@ Warranty card . . . . . . . . . . . . . . . . . . . . . . 1
Contents in the Accessory Bag (No. 1) 8
1. Flat head screw (M5 u 8) . . . . . . . . . . . . . . 8
2. Sems hexagonal screw (M5 u 8). . . . . . . . 8
3. Electro tap . . . . . . . . . . . . . . . . . . . . . . . . . 2
4. Electro tap for speed sensor . . . . . . . . . . 1
5. Double-sided tape for fastening
antenna. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
6. Lead holder . . . . . . . . . . . . . . . . . . . . . . . 10
7. Double-sided tape for microphone . . . . . 1
Contents in the Accessory Bag (No. 2) 9
8. Rubber cap for RCA pin lead . . . . . . . . . . 6
2
1
3
4
5
6
8 97
0
!
@
3
2
1
4
5 7
6
8
