Note:
*1: Connecting the PHONE INTERRUPT terminal
The phoe interrupt will mute the audio if the lead receives a negative or ground signal.
Yellow
Black
Ground
+12V main power
Orange/white Illumination
Blue
Red
Brown
Blue/white
Grass-green
Purple/white
Purple/black
Purple
Gray/black
Gray
White
White/black
Green
Green/black
Auto antenna
+12V accessory
Phone interrupt
Amplier turn-on cord
Parking brake cord
Reverse gear cord
Rear right-
Rear right+
Rear left+
Rear left-
Front right-
Front right+
Front left+
Front left-
15A
