25. WIRE CONNECTION GUIDE
Note:
• Before installing, be sure to disconnect the negative cable of the car battery.
• In the optional devices, the RCA cables and the Connector cables are separately-sold items.
• When connect the HDMI and USB cable, be sure to x with the clamp.
Refer to
next page
DTX502E or DAB404E
GPS Antenna
Radio Antenna
YELLOW WHITE RED RED RED REDWHITE WHITE WHITE
4-Channel Amlier
YELLOW YELLOW
RED
WHITE
CAMERA VIDEO OUT REAR_RCH REAR_LCH MIC
AUX2 VIDEO IN AUX2 AUDIO IN LCH AUX2 AUDIO IN RCH SUBWOOFER 1 SUBWOOFER 2
SWI
HDMI CABLE
CCA-750 (sold separately)
Video Out
Rear Vision Camera
Monitor
iPod/iPhone
