CLARKE TECHNOLOGY Operator's Manual - C2K Series 120V Page - 29 -
Ref. Part No. Description Qty.
1 85383A Screw, 10-32 x
3
/4 10
2 50779A Handle, Front 1
3 50798A Lever, Switch 2
4 50820A Spring, Extension 2
5 50806A Button, Interlock 1
6 40109A Switch 2
7 50799A Interlock, Main 1
8 50821A Spring, Compression 1
9 50780A Handle, Rear 1
10 920722 Nut, 10-32 ESNA 7
11 962957 Screw 2
13 10092A Cord, Interconnect 1
14 461404 Cam, Locking (included in 42) 1
15 925592 Roll Pin, ¼ (included in 42) 1
16 441301 Bolt, Locking Cam
(included in 42)
1
17 980349 Washer, Wear Cam 1
18 50791A Arm Link, RH 1
19 50781A Clamp, Handle 1
20 50792A Arm Link, LH 1
21 980645 Washer, Flat
3
/8 1
22 920342 Nut,
3
/8 -16 ESNA 2
23 87035A Washer, Fender #10 SS 2
24 50793A Wheel, 5" 2
25 87050A Washer,
5
/8 Nylon 2
26 50794A Bushing, Nylon 2
27 80087A Screw,
3
/8 -16 x 6 1
28 57120A Plug, Button 1
29 50955A Motor,
3
/4 HP (16, 18) 1
44635A Motor, 1 HP (160, 180, 200) 1
50858B Motor, 1.5 HP (1600) 1
50858A Motor, 1.5 HP (1800, 2000) 1
30 54409A Gearbox (16, 18, 160, 180, 200) 1
52093A Gearbox (160HS, 180HS, 200HS) 1
50851A Gearbox (1600, 1800, 2000) 1
31 50822A Cover, Motor (16, 18, 160, 180 1
200, 160HS, 180HS, 200HS)
50823A Cover, Motor (1600, 1800, 2000) 1
32 50790A Frame, Main 1
33 50785A Shield, Brush (16, 160, 1600) 1
50786A Shield, Brush (18, 180, 1800) 1
50787A Shield, Brush (200, 2000) 1
34 50782A Bumper, (16, 160, 1600) 1
50783A Bumper, (18, 180, 1800) 1
50784A Bumper, (200, 2000) 1
36 85817A Screw,
5
/16-18 x 2
1
/8 4
37 50796A Bushing, Cord 1
38 50795A Tube, Handle 1
40 50797A Relief, Strain (included w/41) 1
41 10083A Cord Assembly (includes 40) 1
42 441401 Cam Assembly (incl. 14, 15 & 16) (1)
43 747553 Strain Relief 1
44 77378A Label 1
45 980603 Lockwasher #10 1
46K 170686 Lock nut (not illustrated) 1
47 50930A Cord Retainer 1
CLARKE TECHNOLOGY
C2K-16, C2K-18, C2K-160, C2K-180, C2K-200,
C2K-1600, C2K-1800, C2K-2000, C2K-160HS, C2K-180HS, C2K-200HS
Assembly Drawing Parts List 2/01
Note: K indicates a
change has been made
since last publication of
this manual
To Next Page
