CLARKE TECHNOLOGY Operator's Manual - C2K Series 120V Page - 31 -
CLARKE TECHNOLOGY
C2K-1600DS and C2K-2000DS
Assembly Parts List 2/01
Ref. Part No. Description Qty.
1 85383A Screw, 10-32 x
3
/4 8
2 50779A Handle, Front 1
3 50798A Lever, Switch 2
4 50820A Spring, Extension 2
5 50806A Button, Interlock 1
6 40109A Switch 2
7 50799A Interlock, Main 1
8 50821A Spring, Compression 1
9 50780A Handle, Rear 1
10 920722 Nut, 10-32 ESNA 8
13 10084A Cord, Interconnect 1
14 461404 Cam, Locking (Included in 51) 1
15 925592 Roll Pin, ¼ (Included in 51) 1
16 441301 Bolt, Locking Cam (included in 51) 1
17 980349 Washer, Wear Cam 1
18 50791A Arm Link, RH 1
19 50781A Clamp, Handle 1
20 50792A Arm Link, LH 1
21 980645 Washer, Flat
3
/8 1
22 920342 Nut,
3
/8 -16 ESNA 2
23 87035A Washer, Fender #10 SS 2
24 50793A Wheel, 5" 2
25 87050A Washer,
5
/8 Nylon 2
26 50794A Bushing, Nylon 2
27 80087A Screw,
3
/8 -16 x 6 1
28 57120A Plug, Button 1
29 50825A Bracket 1
30 44651A Motor/Gearbox 1
30a 63602A Gearbox (1)
31 50824A Cover, Motor 1
32 50790A Frame, Main 1
33 50785A Shield, Brush (1600) 1
50787A Shield, Brush (2000) 1
34 50782A Bumper, (1600) 1
50784A Bumper, (2000) 1
36 85817A Screw,
5
/16-18 x 2
1
/8 4
37 50796A Bushing, Cord 1
38 50795A Tube, Handle 1
40 50797A Relief, Strain (included w/54) 1
41 85517A Screw 2
42 70151A Label, Dual Speed 1
43 47402BK Switch SPDT 1
44 57165AK Plug, Nylon Hole 1
45 40181AK Insulated Jumper 1
46 34259A Light 1
47 80201A Clip 1
48 747553 Strain Relief 1
49 77200A Label, (High-Low) 1
50 77378A Label 1
51 441401 Cam Assembly
(incl. 14, 15, & 16) (1)
52 30605A Baffle 1
54 10083A Cord Assembly (includes 40) 1
55 170686K Locknut 1
56 962957 Screw 1
57 50930A Cord Retainer 1
Note: K indicates a
change has been made
since last publication of
this manual
To Next Page
