NOTE: The PowerView diagnostic gauge can have
communication problems that result in Error Codes
being shown on its LCD display window. The
following Error Codes all indicate that there is a
Diagnostic Gauge communication error with the
ECM. Contact your servicing dealer for help in
correcting these codes:
EE – Error XXXXX – EP
No Data
ACP – Err XXXXX - BO
No Addr No Data
ACP – Err XXXXX - BR
BUS – EP No Data
NOTE: Refer to wiring diagnostic earlier in this
section as a guide to connections and wires.
6.0 PARTS INFORMATION
6.1 SPARE PARTS
To ensure best operation and efficiency of all engine
components, always use genuine Clarke spare parts.
Orders should specify:
Engine Model Number - See Engine General
Engine Serial Number - Specification
Part Number(s) Refer to Engine Maintenance
Parts List section 6.2 or Parts Illustration (see
Page 5).
Contact numbers for spare parts:
• www.clarkefire.com
• Phone USA: (513) 771-2200 Ext. 427 (calling
within USA)
• Phone UK: (44) 1236 429946 (calling outside USA)
• Fax USA: (513) 771-5375 (calling within USA)
• Fax UK: (44) 1236 427274 (calling outside USA)
• E-Mail USA: parts@clarkefire.com
• E-Mail UK: dmurray@clarkefire.com
6.2 ENGINE MAINTENANCE PARTS LIST
Refer to Appendix “A” at the end of this manual.
7.0 OWNER ASSISTANCE
Consult Clarke Service Dealer or Factory. Service
Dealers can be located by going to our website:
www.clarkefire.com.
8.0 WARRANTY
8.1 GENERAL WARRANTY STATEMENT
The satisfactory performance of Clarke engines and
the goodwill of owners/operators of Clarke engines
are of primary concern to the Engine Manufacturer,
the Engine Service Dealer and Clarke. All provide
support of these products after final installation of the
complete fire pump and sprinkler system.
Warranty responsibility involves both Clarke and the
Caterpillar service organizations worldwide.
The Engine Manufacturer, (Caterpillar) provides
Warranty for the basic engine components and Clarke
provides warranty on the accessories added to meet
the NFPA-20 specifications and UL/FM certification
requirements.
8.2 CLARKE WARRANTY
All Clarke warranted components have warranty
duration of 24 months beginning at the Start-up date
of the fire pump system. The warranty coverage
includes replacement of the part and reasonable cost
of labor for installation. Components failed due to
improper engine installation, transportation damage,
or misuse is not covered under this warranty.
For additional warranty details, see the specific
warranty statement “Caterpillar New Engine
Warranty” in Appendix B. Contact Clarke directly if
you have any questions or require additional
information.
Clarke is not responsible for incidental or
consequential costs, damage or expenses which the
owner may incur as a result of a malfunction or
failure covered by this warranty.
8.3 CATERPILLAR WARRANTY
The Caterpillar Limited Warranty is reprinted, in its
entirety, in Appendix B. It outlines Caterpillar
Responsibilities, User Responsibilities, and Warranty
Durations.
9.0 INSTALLATION AND OPERATION DATA
(See www.clarkefire.com)
10.0 WIRING DIAGRAMS
(See www.clarkefire.com)
11.0 PARTS ILLUSTRATION DRAWINGS
