Clevo PB70DDS - Page 15

Introduction
Specifications 1 - 3
1.Introduction
Storage
One changeable 2.5" (6cm) 7.0mm (h) SATA (Serial) Hard
Disk Drive/Solid State Drive (SSD)
(Factory Option) One M.2 2280 SATA Solid State Drive
(SSD)
Or
(Factory Option) Two M.2 2280 PCIe Gen3 x4 SSDs sup-
porting RAID level 0/1
Audio
High Definition Audio Compliant Interface
S/PDIF Digital Output
Built-In Array Microphone
Two Speakers
One Subwoofer
Sound Blaster Atlas
Communication
1.0M HD PC Camera Module
Built-In 10/100/1000Mb Base-TX Ethernet LAN
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wireless-AC 9560 Wire-
less LAN (802.11ac) + Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 6 AX201 Wireless
LAN (802.11ax) + Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 6 AX201 Wireless
LAN (802.11ax) + Bluetooth
(Factory Option) Killer™ Dual Band
Wi-Fi 6 AX1650i Wireless LAN (802.11ax) + Bluetooth
Card Reader
Embedded Multi-In-1 Push-Push Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for SATA or PCIe Gen3 x4 SSD
Slot 3 for PCIe Gen3 x4 SSD
Interface
One USB 3.2 Gen 2 Type-C Port*
*The maximum amount of current supplied by USB Type-C
ports is 500mA (USB 2.0)/900mA (USB 3.2).
Or
(Factory Option) One Thunderbolt 3 Port
Three USB 3.2 Gen 1 Type-A Ports (Including one AC/DC
Powered USB Port)
One DisplayPort 1.4 over USB 3.2 Gen 2 Type-C Port
One Mini DisplayPort 1.4
One HDMI-Out Port
One 2- In-1 Audio Jack (Microphone and S/PDIF Optical)
One 2- In-1 Audio Jack (Headphone and Microphone)
One RJ-45 LAN Jack
One DC-In Jack
Features
Supports NVIDIA® G-SYNC™ Technolgy in DISCRETE
Mode
(NVIDIA® G-SYNC™ Technology is supported by some dis-
plays)
Intel® Optane™ Technology
Virtual Reality Ready
Windows® Mixed Reality Compatible
(Factory Option) USB Drive
Environmental Spec
Temperature
Operating: 5°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Removable 6 Cell Smart Lithium-Ion Battery Pack, 62WH
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 11.8A (230W)
Dimensions & Weight
399mm (w) * 275mm (d) * 29.9mm (h)
2.9kg (Barebone with 62WH Battery)
