Upgrading The Computer
Upgrading the Optical (CD/DVD) Device 6 - 11
6
Removing the Optical Device for Model B/D Computers
1. Turn off the computer, and turn it over and remove the battery.
2. Locate the hard disk bay cover and remove screws & .
3. Remove the hard disk bay cover .
4. Slide the hard disk in the direction of arrow and lift the hard disk out of the bay.
Figure 6 - 6
Hard Disk Removal
1
2
3
4
3
4
