1 - 20 3G Module USIM Card Installation
Quick Start Guide
1
3G Module USIM Card Installation
If you have included an optional 3G module in your purchase option (Factory Option for Model A & C Com-
puters Only), follow the instructions below to install the USIM card (which will be provided by your service
provider), and then run the Wireless Manager application. See “Wireless Manager” on page 7 - 35 for instruc-
tions on installing the program etc.
1. Turn off the computer, and turn it over and then remove the battery (slide the latches in the direction indicated
below and slide the battery out).
2. Insert the USIM card (at the rear of the battery compartment) as illustrated below until it clicks fully into position,
and replace the battery.
Figure 1 - 13 - Battery Removal & USIM Card Insertion
USIM Card
Orientation
Note that the USIM
card’s readable side
(with the gold-colored
contacts) should face
upwards as illustrated.
To Next Page
