SCALE 1 : 1
5
Installation Instructions
1 Stage Heat, 1 stage Cool
(gas/elec)
1
GAS
O
GAS/EL
ELEC
B
HP
ON
23
1
GAS
O
GAS/EL
ELEC
B
HP
ON
23
Dip Switch Settings
C
W2
W1
O
Y2
Y1
G
R
Thermostat
HVAC
Equipment
Condensate
Switch
(optional)
D / H
RS
R
G
Y1
W
O
Y2
C
CK1
Note: Set DRY CONTACT USE (setup step #29)
to CONDENSATE
