Electrical – Line Voltage, Cont’d.
Table 4f: Tranquility
®
20 (TS) Series Electrical Data - (ECM Motor & Secondary Pump)
All TS Units with ECM Fan Motor TS Units (ECM)
TS Units with ECM Fan Motor
and Secondary Pump
Model
Voltage
Code
Rated
Voltage
Voltage
Min/Max
Compressor
Fan
Motor
FLA
Total
Unit
FLA
Min
Circuit
Amp
Max
Fuse/
HACR
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amp
Max
Fuse/
HACR
QTY RLA LRA
018
G 208/230/60/1 197/254 1 9.0 48.0 3.9 12.9 15.2 20 0.4 13.3 15.6 20
E 265/60/1 239/292 1 8.4 40.0 3.2 11.6 13.7 20 0.7 12.3 14.4 20
024
G 208/230/60/1 197/254 1 13.5 58.3 3.9 17.4 20.8 30 0.4 17.8 21.2 30
E 265/60/1 239/292 1 9 54.0 3.2 12.2 14.5 20 0.7 12.9 15.2 20
H 208/230/60/3 197/254 1 7.1 55.4 3.9 11.0 12.8 15 0.4 11.4 13.2 20
F* 460/60/3* 414/506 1 3.5 28.0 3.2 6.7 7.6 15 0.7 7.4 8.3 15
030
G 208/230/60/1 197/254 1 12.8 64.0 3.9 16.7 19.9 30 0.8 17.5 20.7 30
E 265/60/1 239/292 1 10.9 60.0 3.2 14.1 16.8 25 0.7 14.8 17.5 25
H 208/230/60/3 197/254 1 8.3 58.0 3.9 12.2 14.3 20 0.8 13.0 15.1 20
F* 460/60/3* 414/506 1 5.1 28.0 3.2 8.3 9.6 15 0.7 9.0 10.3 15
036
G 208/230/60/1 197/254 1 16.0 77.0 3.9 19.9 23.9 35 0.8 20.7 24.7 40
E 265/60/1 239/292 1 12.2 72.0 3.2 15.4 30.7 30 0.7 16.1 19.2 30
H 208/230/60/3 197/254 1 10 71.0 3.9 13.9 16.4 25 0.8 14.7 17.2 25
F* 460/60/3* 414/506 1 4.7 38.0 3.2 7.9 9.1 15 0.7 8.6 9.8 15
042
G 208/230/60/1 197/254 1 16.7 79.0 3.9 20.6 24.8 40 0.8 21.4 25.6 40
E 265/60/1 239/292 1 13.5 72.0 3.2 16.7 20.1 30 0.7 17.4 20.8 30
H 208/230/60/3 197/254 1 10.4 73.0 3.9 14.3 16.9 25 0.8 15.1 17.7 25
F* 460/60/3* 414/506 1 5.8 38.0 3.2 9.0 10.5 15 0.7 9.7 11.2 15
048
G 208/230/60/1 197/254 1 21.8 117.0 6.9 28.7 34.2 50 0.8 29.5 35.0 50
E 265/60/1 239/292 1 16.3 98.0 6.0 22.3 26.4 40 0.7 23. 27.1 40
H 208/230/60/3 197/254 1 13.7 83.1 6.9 20.6 24.0 35 0.8 21.4 24.8 35
F* 460/60/3* 414/506 1 6.2 41.0 6.0 12.2 13.8 20 0.7 12.9 14.5
20
060
G 208/230/60/1 197/254 1 26.4 134.0 6.9 33.3 39.9 60 1.1 34.4 41.0 60
E 265/60/1 239/292 1 19.9 130.0 6.0 25.9 30.9 50 1.3 27.2 32.2 50
H 208/230/60/3 197/254 1 16 110.0 6.9 22.9 26.9 40 1.1 24.0 28.0 40
F* 460/60/3* 414/506 1 7.8 52.0 6.0 13.8 15.8 20 1.3 15.1 17.1 20
070
G 208/230/60/1 197/254 1 30.8 178.0 6.9 37.7 45.4 70 1.1 37.9 45.6 70
H 208/230/60/3 197/254 1 19.6 138.0 6.9 26.5 31.4 50 1.1 27.6 32.5 50
F* 460/60/3* 414/506 1 8.2 66.1 6.0 14.2 16.3 20 1.3 15.5 17.6 25
* NEUTRAL CONNECTION REQUIRED! All F Voltage (460 vac) units with ECM motors/internal secondary circulators require a four wire power supply with neutral. ECM motors/internal secondary
circulators are rated 265 vac and are wired between one hot leg and neutral.
