CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
20 (TS) Series
Rev.: June 5, 2020
ClimateMaster Water-Source Heat Pumps
24
Electrical – Line Voltage, Cont’d.
All TS Units with High Static PSC Fan Motor TS (H.S. PSC) Units
TS Units with H.S. PSC Fan Motor and
Secondary Pump
Model
Voltage
Code
Rated
Voltage
Voltage
Min/Max
Compressor
Fan
Motor
FLA
Total
Unit
FLA
Min
Circuit
Amp
Max
Fuse/
HACR
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amp
Max
Fuse/
HACR
QTY RLA LRA
018
G 208/230/60/1 197/254 1 9.0 48.0 1.1 10.1 12.4 20 0.4 10.5 12.8 20
E 265/60/1 239/292 1 8.4 40.0 0.9 9.3 11.4 15 0.7 10.0 12.1 20
024
G 208/230/60/1 197/254 1 13.5 58.3 1.8 15.3 18.7 30 0.4 15.7 19.1 30
E 265/60/1 239/262 1 9 54.0 1.4 10.4 12.7 20 0.7 11.1 13.4 20
H 208/230/60/3 197/254 1 7.1 55.4 1.8 8.9 10.7 15 0.4 9.3 11.1 15
F* 460/60/3* 414/506 1 3.5 28.0 1 4.5 5.4 15 0.7 5.2 6.1 15
030
G 208/230/60/1 197/254 1 12.8 64.0 2.2 15.0 18.2 30 0.8 15.8 19.0 30
E 265/60/1 239/292 1 10.9 60.0 1.7 12.6 15.3 25 0.7 13.3 16.0 25
H 208/230/60/3 197/254 1 8.3 58.0 2.2 10.5 12.6 20 0.8 11.3 13.4 20
F* 460/60/3* 414/506 1 5.1 28.0 1.0 6.1 7.4 15 0.7 6.8 8.1 15
036
G 208/230/60/1 197/254 1 16.0 77.0 2.2 18.2 22.2 35 0.8 19.0 23.0 35
E 265/60/1 239/292 1 12.2 72.0 1.7 13.9 29.2 25 0.7 14.6 17.7 25
H 208/230/60/3 197/254 1 10 71.0 2.2 12.2 14.7 25 0.8 13.0 15.5 25
F* 460/60/3* 414/506 1 4.7 38.0 1.0 5.7 6.9 15 0.7 6.4 7.6 15
042
G 208/230/60/1 197/254 1 16.7 79.0 2.7 19.4 23.6 35 0.8 20.2 24.4 40
E 265/60/1 239/292 1 13.5 72.0 2.9 16.4 19.8 30 0.7 17.1 20.5 30
H 208/230/60/3 197/254 1 10.4 73.0 2.7 13.1 15.7 25 0.8 13.9 16.5 25
F* 460/60/3* 414/506 1 5.8 38.0 1.7 7.5 9.0 15 0.7 8.2 9.7 15
N 575/60/3 518/633 1 3.8 36.5 1.4 5.2 6.2 15 N/A N/A N/A N/A
048
G 208/230/60/1 197/254 1 21.8 117.0 2.6 24.4 29.9 50 0.8 25.2 30.7 50
H 208/230/60/3 197/254 1 13.7 83.1 2.6 16.3 19.7 30 0.8 17.1 20.5 30
F* 460/60/3* 414/506 1 6.2 41.0 1.8 8.0 9.6 15 0.7 8.7 10.3
15
N 575/60/3 518/633 1 4.8 33.0 1.4 6.2 7.4 15 N/A N/A N/A N/A
060
G 208/230/60/1 197/254 1 26.4 134.0 4.0 30.4 37.0 60 1.1 31.5 38.1 60
H 208/230/60/3 197/254 1 16 110.0 4.0 20.0 24.0 35 1.1 21.1 25.1 40
F* 460/60/3* 414/506 1 7.8 52.0 2.6 10.4 12.4 15 1.3 11.7 13.7 20
N 575/60/3 518/633 1 5.7 38.9 1.5 7.2 8.6 15 N/A N/A N/A N/A
* NEUTRAL CONNECTION REQUIRED! All F Voltage (460 vac) units with internal secondary circulators require a four wire power supply with neutral.
Internal secondary circulators are rated 265 vac and are wired between one hot leg and neutral.
Table 4e: Tranquility
®
20 (TS) Series Electrical Data - (PSC High Static Motor & Secondary Pump)
