EVH-X SPACE 2.1 - 12.1
M0SM10N17-03
UNIT PARAMENTERS
GRUP. ID MNEMONICO DESCRIPTION
SET
PA01 SetpointComfort Point de consigne confort (default)
PA02 MaxSet Max configurable set, both Eco and Confort
PA03 MinSet Min configurable set, both Eco and Confort
PA04 SetCoolEco Standard Set Eco in Cool
PA05 SetHeatEco Standard Set Eco in Heat
PA06 MaxOffsetSet Max. correction accepted to the set point from the thermostat
PA07 ZonaNeutraComfort Neutral zone for the Auto mode in confort
PA08 ZonaNeutraEco Neutral zone for the Auto mode in Eco
PA09 IsteresiHeat Thermoregulation hysteresis in Heat
PA10 IsteresiAux Thermoregulation hysteresis in Heat for Aux
PA11 IsteresiCool Thermoregulation hysteresis in Cool
PA12 FBandIsteresiEco Value to sum to thermoregulation hysteresis when ECO mode is active
PA13 TimerOverride Random time between 0 and TimerOverride seconds for step insertion/release
SORG
PB01 SetLowSorgHeat Low temperature thereshold source water
PB02 SetHiSorgCool High temperature thereshold source water
PB03 IstLowTempSorg Hysteresis for reset of high and low source temperature thereholds
PB04 MinApValvSorg Min. source valve opening
PB05 MaxApValvSorg Max. source valve opening
PB06 StartApValvSorg Percentage of source valve opening at the start up
PB07 TStartValvSorg Valve opening time at % StartApValvSorg source
UTIL
PC03 VccMinFanCool Min voltage applicable to control 0-10 Vdc in Cool
PC04 VccMaxFanCool Max voltage applicable to control 0-10 Vdc in Cool
PC05 VccMinFanHeat Min voltage applicable to control 0-10 Vdc in Heat
PC06 VccMaxFanHeat Max voltage applicable to control 0-10 Vdc in Heat
PC07 RitCpDaFan Compressor activation delay from utility fan start
PC08 RitOffFanDaCp Delay of utility fan stopping from compressor Off
PC09 RitOffFanDaAux Delay of utility fan stopping from Off of the aux heater
PC18 FilterAlarmTimer Time interval setting for air filter maintenance
CNF
PD05 SetAllLP Low pressure alarm Set point from analogical input
PD06 DeltaAllLP Hysteresis of low pressure alarm reset from analogical input
TARA
PE01 OffsetAI1 Setting of AI1 analogical input (Return Temperature I/O )
PE02 OffsetAI2 Setting of AI2 analogical input (Return Temperature from sensor thermostat)
PE03 OffsetAI3 Setting of AI3 analogical input (Output water Temperature source I/O )
PE04 OffsetAI4 Setting of AI4 analogical input (Exchanger Temperature treatment coil utility I/O )
PE05 OffsetAI5 Setting of AI5 analogical input (Electronic thermostatic return Temperature )
PE06 OffsetAI6 Setting of AI6 analogical input (High/low Pressure )
PE07 OffsetAI7 Setting of AI7 analogical input (Electronic thermostatic return pressure )
PE08 OffsetAITer Setting of the ambient probe analogical input on thermostat board
BMS *
PF01 AddressTh ModBus address of the thermostat (Slave)
PF02 BaudRateTh Serial communication speed for thermostat 0=2400 1=4800 2=9600 3=19200
PF03 ParityTh Thermostatparity 0=No 1= Odd 2=Even
PF04 Address ModBus address of the WLHP for the supervisor
PF05 BaudRate Communication speed of the supervision serial 0=2400 1=4800 2=9600 3=19200
PF06 Parity Parity of the supervision serial 0=No 1= Odd 2=Even
U.M.
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
sec.
°C
°C
°C
%
%
%
sec.
%
%
%
%
sec.
sec.
sec.
days
bar
bar
°C
°C
°C
°C
°C
bar
bar
°C
-
-
-
-
-
-
PC16 MinFanAuxOn Min percentage of utility fan if Aux=ON %
* the modification of these parameters makes impossible the communication between thermostat and unit
The parameters accessible by password or supervision system can be modified only by qualified personnel
after having read the specific manuals of the electronic system and of the supervision protocols.
9 CONTROL
