TEMPERATURE SENSOR RESISTANCE CHARACTERISTICS
116
Compressor discharge pipe temperature sensor resistance characteristics
Temp. (°C) Res. (kΩ) Temp. (°C) Res. (kΩ) Temp. (°C) Res. (kΩ) Temp. (°C) Res. (kΩ)
-20 542.7 20 68.66 60 13.59 100 3.702
-19 511.9 21 65.62 61 13.11 101 3.595
-18 483.0 22 62.73 62 12.65 102 3.492
-17 455.9 23 59.98 63 12.21 103 3.392
-16 430.5 24 57.37 64 11.79 104 3.296
-15 406.7 25 54.89 65 11.38 105 3.203
-14 384.3 26 52.53 66 10.99 106 3.113
-13 363.3 27 50.28 67 10.61 107 3.025
-12 343.6 28 48.14 68 10.25 108 2.941
-11 325.1 29 46.11 69 9.902 109 2.860
-10 307.7 30 44.17 70 9.569 110 2.781
-9 291.3 31 42.33 71 9.248 111 2.704
-8 275.9 32 40.57 72 8.940 112 2.630
-7 261.4 33 38.89 73 8.643 113 2.559
-6 247.8 34 37.30 74 8.358 114 2.489
-5 234.9 35 35.78 75 8.084 115 2.422
-4 222.8 36 34.32 76 7.820 116 2.357
-3 211.4 37 32.94 77 7.566 117 2.294
-2 200.7 38 31.62 78 7.321 118 2.233
-1 190.5 39 30.36 79 7.086 119 2.174
0 180.9 40 29.15 80 6.859 120 2.117
1 171.9 41 28.00 81 6.641 121 2.061
2 163.3 42 26.90 82 6.430 122 2.007
3 155.2 43 25.86 83 6.228 123 1.955
4 147.6 44 24.85 84 6.033 124 1.905
5 140.4 45 23.89 85 5.844 125 1.856
6 133.5 46 22.89 86 5.663 126 1.808
7 127.1 47 22.10 87 5.488 127 1.762
8 121.0 48 21.26 88 5.320 128 1.717
9 115.2 49 20.46 89 5.157 129 1.674
10 109.8 50 19.69 90 5.000 130 1.632
11 104.6 51 18.96 91 4.849
12 99.69 52 18.26 92 4.703
