TEMPERATURE SENSOR RESISTANCE CHARACTERISTICS
114
9. Temperature sensor resistance characteristics
Outdoor ambient temperature sensor, water side heat exchanger refrigerant inlet/outlet (liquid/gas pipe) temperature
sensor, air side heat exchanger refrigerant outlet temperature sensor and suction pipe temperature sensor resistance
characteristics
Temp. (°C) Res. (kΩ) Temp. (°C) Res. (kΩ) Temp. (°C) Res. (kΩ) Temp. (°C) Res. (kΩ)
-25 144.266 15 16.079 55 2.841 95 0.708
-24 135.601 16 15.313 56 2.734 96 0.686
-23 127.507 17 14.588 57 2.632 97 0.666
-22 119.941 18 13.902 58 2.534 98 0.646
-21 112.867 19 13.251 59 2.44 99 0.627
-20 106.732 20 12.635 60 2.35 100 0.609
-19 100.552 21 12.05 61 2.264 101 0.591
-18 94.769 22 11.496 62 2.181 102 0.574
-17 89.353 23 10.971 63 2.102 103 0.558
-16 84.278 24 10.473 64 2.026 104 0.542
-15 79.521 25 10 65 1.953 105 0.527
-14 75.059 26 9.551 66 1.883
-13 70.873 27 9.125 67 1.816
-12 66.943 28 8.721 68 1.752
-11 63.252 29 8.337 69 1.69
-10 59.784 30 7.972 70 1.631
-9 56.524 31 7.625 71 1.574
-8 53.458 32 7.296 72 1.519
-7 50.575 33 6.982 73 1.466
-6 47.862 34 6.684 74 1.416
-5 45.308 35 6.401 75 1.367
-4 42.903 36 6.131 76 1.321
-3 40.638 37 5.874 77 1.276
-2 38.504 38 5.63 78 1.233
-1 36.492 39 5.397 79 1.191
0 34.596 40 5.175 80 1.151
1 32.807 41 4.964 81 1.113
2 31.12 42 4.763 82 1.076
3 29.528 43 4.571 83 1.041
4 28.026 44 4.387 84 1.007
5 26.608 45 4.213 85 0.974
6 25.268 46 4.046 86 0.942
