7 - CONTROL
Menu Code Description
Ai
AiE1 DHW temperature
Ai L1
Primary outlet temperature
Ai L2
Primary inlet temperature
Ai L3
Coil temperature
Ai L4
High pressure transducer
Ai L5
Outdoor temperature
1Ai 1
Low pressure transducer (thermostatic sensor on the driver)
1Ai 2
Return temperature (thermostatic sensor on the driver)
1Ai 3
Discharge temperature (thermostatic sensor on the driver)
di
di L1
High pressure
di L2
Compressor Alarm
di L3
Flow utility side
di L4
Remote On-Off
di L5 Remote Heat/Cool
AO
AO L1 Primary pump (it is a digital 0/1)
AO L2
Fan signal
AO L3
Compressor signal
AO L4
Primary pump signal (if in variable flow )
dO
dOE1
DHW heater (if present)
dO L1
DHW valve
dO L2
Reversing valve refrigerant circuit
dO L3
Frost Heater
dO L4
Auxiliary Heater
dO L5
Compressor start
dO L6
Cumulative alarm
E1
1rE1 Superheating temperature
1rE2 Condensing saturate temperature
1rE5 Superheating
1rE6 Gas pressure (=1Ai1)
1rE7 Opening percentage electronic thermostatic valve
1SP4 Superheating Setpoint
Sr
Actual Setpoint : setpoint with compensation / operating limit
CP01 Hours compressor: dozens
PU01 Hours utility pump: dozens
Hr
7.7 STATA
Main menu
SET
Ai - di - AO - dO
Ai L1
Stata display
To Next Page
