31
P/N 192047138 Rev AA November 2017
CONTROL STATION (ORANGE) FOR USE ON 115 1-50/60
HOISTS WITHOUT CONTACTOR
PARTS LIST
Key No. No. Part Name Required Part Number
620-186
Control station with retainer,
screws and grommet
1 24807
CONTROL STATION (BLACK) FOR USE ON 115-1-50/60
HOISTS WITH CONTACTOR, 220-1-50 AND THREE
PHASE UNITS
CONTROL STATION
Key No. No. Part Name Required Part Number
624-232
Control Station (Includes
624-301 thru 624-307)
1 36900B
624-252 Warning Label (Electrical) 1 24842
624-253 Manufacturer Label 1 28470
624-301 Control Station Grommet 1 36989
624-302 Control Station Housing 1 36998B
624-303 Gasket 1 36986
624-304
Control Station Button
Assembly
1 36988
624-306 Control Station Parts Kit 1 36939
624-307
Contact Assembly
(Includes 624-304)
1 36987
624-308 Warning Label 1 24845
CONTROL STATIONS
