CM Shopstar - Repair Parts List and Ordering

25
P/N 192047138 Rev AA November 2017
REPAIR PARTS LIST
Using “Commercial” or other manufacturer’s parts to repair the CM
Shopstar Hoists may cause load loss.
TO AVOID INJURY
Use only CM supplied replacement parts. Parts may look alike but
CM parts are made of specic materials or processed to achieve
specic properties.
ORDERING INSTRUCTIONS
The following information must accompany all correspondence
orders for replacement parts:
1. Hoist Model Number from identication plate.
2. Serial number of the hoist stamped below identication plate.
3. Voltage, phase, hertz from the identication plate.
4. Length of lift.
5. Part number of part from parts list.
6. Number of parts required.
7. Part name from parts list.
Note
When ordering replacement parts, it is recommended that
consideration be given to the need for also ordering such items as
gaskets, fasteners, insulators, etc. These items may be damaged
or lost during disassembly or just unt for future use because of
deterioration from age or service.
RECOMMENDED SPARE PARTS
To insure continued service of the Shopstar Hoist, the following is a
list of parts that are recommended to be kept on hand at all times to
replace parts that have worn or failed. Parts applicable to your hoist
should be stocked.
Part Name Part Quantity
Contact manufacturer Brake field assem. 1
20698 Brake disc 1
Contact manufacturer Capacitor 1
20709 Cut-out device 1
Contact manufacturer Transformer 1
Contact manufacturer Reversing contactor 1
Contact manufacturer Control station 1
Contact manufacturer Control station parts kit 1
