SPECIFICATIONS
Standard features of the Electric Chain Hoist include:
• Alloy steel, oblique lay liftwheel that provides constant chain
speed and reduces chain wear.
• Hoistaloy® load chain for long and dependable service.
• Grease lubricated, hardened spur gears provide smooth and
quiet operation.
• Thermally protected, hoist duty motor.
• Forged steel upper and lower hooks with latch.
• ProtectorTM that prevents lifting dangerous overloads.
• D.C. disc type motor brake plus regenerative braking.
• 10 foot (3 M) lift. Longer lifts can be supplied on a per order basis.
• 6 foot (1.8 M) power cord with three prong plug for grounding on
115-1-50/60 units. 6 foot (1.8 M) power cord with provisions for
grounding is standard on 220-1-50 and three phase units.
• Rugged NEMA 4 (weatherproof) control station is suspended
on a TYPE SO cord six feet (2.8 M) below the bottom of the
hoist. Longer cords can be provided on a per order basis.
• Lightweight die cast aluminum frames and covers.
• Ball or needle bearings at all rotating points.
• Compact, yet rugged, design provides minimum headroom
and long, trouble-free service
• 220-1-50, 380 to 460-3-50/60, 220 to 240-3-50/60 and 575-3-60
units available. Lift speeds are based on 60 hertz power supply.
For 50 hertz power supply lift speeds will be 5/6 of those indicated.
• Speeds and capacities based on Table 1, below.
• UL and cUL listed.
• Lifetime Warranty.
Follow all instructions and warnings for inspecting, maintaining
and operating this hoist.
The use of any hoist presents some risk of personal injury or
property damage. That risk is greatly increased if proper instructions
and warnings are not followed. Before using this hoist, each operator
should become thoroughly familiar with all warnings, instructions,
and recommendations in this manual.
Retain this manual for future reference and use.
Forward this manual to the hoist operator. Failure to operate the
equipment as directed in the manual may cause injury. Before
putting hoist into service, ll in the information below. Refer to the
hoist identication plate.
Model Number
Serial No.
Purchase Date
Voltage
Rated Load
Table 1 - Specifications
Lift
6
fpm
8 fpm
12
fpm
13.3
fpm
16
fpm
20
fpm
24
fpm
40
fpm
250 lb x x x
300 lb x x x x
500 lb x x x x x
550 lb x
600 lb x x
1000 lb x x x
REPAIR/REPLACEMENT POLICY
All Electric Chain Hoists are inspected and performance
tested prior to shipment. If any properly maintained hoist
develops a performance problem, due to a material or
workmanship defect, as veried by the factory, repair or
replacement of the unit will be made to the original purchaser
without charge. This repair/replacement policy applies only to
Shopstar Hoists installed, maintained and operated as outlined
in this manual, and specically excludes hoists subject to normal
wear, abuse, improper installation, improper or inadequate
maintenance, hostile environmental effects and unauthorized
repairs/modications.
We reserve the right to change materials or design if, in our opinion,
such changes will improve our product. Abuse, repair by an
unauthorized person, or use of non-factory replacement parts
voids the guarantee and could lead to dangerous operation.
All Shopstar Electric Chain Hoists are backed with a lifetime
warranty. Refer to the back cover for details and limitations.
Alterations or modication of hoist and use of non-factory repair
parts can lead to dangerous operation and injury.
TO AVOID INJURY:
• Do not alter or modify equipment.
• Do use only factory replacement parts.
