MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 17 of 126
It consists of an electrical panel in which there are:
• the SK key: through it, it is possible to turn on
the electric system and start the endothermic
engine;
• the hour counter;
• the green light 5 indicating system power
supply: it is on when the SK key is in position
1;
• the red light 4 which signals low pressure
to the engine oil;
• the red light 3 which monitors coolant lev-
el;
• the orange light 2 indicating the spark
plugs working;
• the red light 1 which signals an alternator
failure;
• the control station selector 6: at left it ena-
bles the basket control station, at right the ra-
dio control on the ground
• the platform consent light 7: if lighted on, it
allows the maneuvers of the aerial part only
with stabilization correctly performed.
• the stabilization consent light 8: if lighted
on, it allows the movement of the outriggers
only with the boom and the pantograph rested
on their supports.
• the fuse box;
• the emergency red mushroom-shaped but-
ton EB that blocks the machine, removing the
power supply to the control circuits. This button
has priority over all other commands; thus, it
allows only manual descent to the ground.
The emergency button has a mechanical
locking device; therefore, it must be un-
locked by turning it clockwise to reacti-
vate the normal machine working.
• the “dead man” outriggers button 9: it must
be held pressed together with other levers of
outriggers control station to stabilize or desta-
bilize.
