MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 27 of 126
7. EARLY WARNING LIGHT - MOMENT
LIMITER
8. LED – 85-100% BATTERY CHARGE
(*optional)
9.
10. LED – FRAME LEVELLED
11.
12. LED – BASKET CENTRED
13.
14.
15. WARNING LIGHT – MOMENT
LIMITER BLOCK
16. LED – 60-85% BATTERY CHARGE
(*optional)
17. LEFT REAR OUTRIGGER TO THE
GROUND
18.
19. RIGHT REAR OUTRIGGER TO THE
GROUND
20. LED – BASKET LEVELLED
21.
22.
23. LED – BASKET OVERLOAD
24. LED – 35-60% BATTERY CHARGE
(*optional)
25. LED – BOOMS CLOSED
26. LED – TURRET CENTRED
27. LED – BOOMS WITHDRAWN
28.
29. LED – AERIAL PART USE CONSENT
30. LED – MACHINE STABILIZED
31. LED – MACHINE READY TO TRAVEL
32. LED – 10-35% BATTERY CHARGE
(*optional).
If all leds of battery* charge flash, a bat-
tery malfunction or a connection missed
(CAN-bus) is signalled.
If only the bottom led (10%) flashes, the
battery* charge is too low (under mini-
mum threshold) and the machine is near
to go in block.
3.2.1.1 Recharge of radio control battery
The radio control is equipped with two interchangeable
batteries (one mounted and one spare).
It is advisable to always keep the unused battery
charged and, in any case, to ensure that it is being
charged during non-working hours.
To charge the battery, simply allocate it in the charging
compartment of the radio control storage location (Pic-
ture 10).
