MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 57 of 126
Picture 28: electropump.
ANY DIFFERENT USE IS ABSOLUTELY
NOT RECOMMENDED. IN FACT, THE
ELECTROPUMP, BY ABSORBING POWER
DIRECTLY FROM THE BATTERY, CAN
PRODUCE THE UNEXPECTED
DISCHARGE OF IT.
It can be activated by:
o button (Picture 29) on the right side of
the radio control;
o lever (Picture 29) under the red sealed
cap, on the left side of switching on/off
box.
Picture 29: electropump activation buttons.
To activate the emergency electropump
from the switching on/off control station,
it will be first necessary to remove the
seal on the red cap, lift it and then press
the black lever below (Picture 29).
