MAN.219 Rev.8 ENG - Use and maintenance manual S19N page 13 of 71
Picture 4d: power supply selector (*optional).
Picture 4e: dual power sockets (*optional).
3.2 Platform control stations
There are different platform control stations:
• platform control station on the basket (Picture 5);
• the travel control station by a wired remote control (Picture 8);
• the outriggers control station (Picture 7);
• platform control (emergency) station on the turret (Picture 10).
It is not possible to use two different control station at the
same time.
By opening the cover of the emergency control station, the
basket control station is disabled.
