CMC S28 User Manual

MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 106 of 138
Operative
temperature (during
charge)
-20/+60*
[°C]
Operative
temperature (during
discharge)
-20/+60
[°C]
Battery Weight
70 approximately
[kg]
Maximum Output
Power
4.8
[kW]
Rated Energy
4.32
[kWh]
*When charge is operated at less than 0°C the charge
current is electronically limited at 10 A.
Battery charger specifics
Voltage Input
100 - 240
Vac
Frequency Input
50 - 60
Hz
Maximum Output Voltage
>=60
V
Maximum Current
22
A
PWM Frequency
1
kHz
International Protection
IP20
Weight
2,2
Kg
Dimension (L*W*H)
180x310x100
mm
8.13 Maintenance of tracks
Stop the MEWP on a solid and plane ground. Lift the
counter frame and check the tensioning of crawlers.
Remove gravel or mud stuck between the gear
wheel and the links of the track, before
proceeding with the tensioning.
The grease contained in the hydraulic crawler is
under pressure. If the tensioning valve is
loosened too much, it risks being expelled under
the effect of the pressure of the grease, seriously
endangering the safety of the operator.
To tension the track, connect a pneumatic gun to the
grease pump and add grease.
To loosen the track, slowly unscrew the tensioning valve
counterclockwise for no more than one turn. If the grease
does not start to drain, slowly rotate the track.
