MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 31 of 138
The AUTEC radio control has the following commands:
Red mushroom-shaped emergency
button that stops the machine
Forward or reverse travel of the left
track / internal or external leveling of the
basket / clockwise or counterclockwise
rotation of the basket
Widening and narrowing of the left track
/ boom 2 in and out
Boom 2 lifting and lowering
Boom 1 out and lifting / boom 1 in and
lowering
Widening and narrowing of the right
track / clockwise or counterclockwise
rotation of turret
Forward or reverse travel of the right
track / jib lifting and lowering
Deadman lever for basket leveling
operations, to be kept shifted upward
during up or down movements of the
joystick J1
On/off lever: upward for endothermic
engine and downward for auxiliary
electric engine (*optional).
Roll-over lever: upward to move front
outriggers and downward to move rear
outriggers.
Speed selector: from minimum “turtle”
speed to maximum “double hare”
speed.
Automatic stabilization/destabilization
lever
The emergency button has an auto-detent
mechanical locking system; therefore, it is
necessary to unlock the button turning it
clockwise to reset its operability.
The functions contained on the radio control
are the same as those of the platform
(exercise) control station in Picture 9 and they
are indicated by the same symbols described
above.
If the battery of the AUTEC radio control is low, it could
become a wired remote control, by connecting the
